Key Specs
- Maximum Lift Capacity: 10000 lb / 4535.92 kg
- Outriggers Up Max Lift Height: 42 ft 1 in. / 12.83 m
- Maximum Lift Height: 42 ft 1 in. / 12.83 m
- Maximum Reach: 26 ft 7 in. / 8.1 m
Key Features
- New, intuitive single joystick controls all boom functions
- Maximize productivity with improved boom speeds
- Redesigned cab includes new dashboard, integrated arm rest and optional air conditioning
- Increased operator confidence with Stabil-Trak rear axle stabilization system when placing a load
- Greater job site versatility—rear counterweight includes an integrated tow hitch
- Optional 74 hp engine doesn’t require Diesel Exhaust Fluid (DEF) and meets Tier 4 Final regulations
Specifications
- Axle-Rear: Oscillating
- Tire Size: 400/75-28
- Frame Leveling: 10 Degrees
- Load Center: 2 ft / 0.61 m
- Drawbar Pull: 24500 lb / 11113.01 kg
- Maximum Engine RPM: 1500 rpm
- Engine Model: QSB3.8L Tier 4 Final
- Speed - Maximum Lift: 16.4 sec.
- Maximum Lift Capacity: 10000 lb / 4535.92 kg
- Ground Clearance: 1 ft 6 in. / 0.46 m
- Engine Horsepower: 110 hp / 82.06 kW
- Outriggers Up Max Lift Height: 42 ft 1 in. / 12.83 m
- Outriggers or Stabilizers: Yes
- Function Pump Type: Var Load Sensing Piston
- Transmission - Nr Reverse Gears: 3
- Machine Length: 20 ft 8 in. / 6.3 m
- Axle-Front: High Bias, Limited Slip
- Transmission - Nr Forward Gears Standard: 4
- Transmission Type: Powershift
- Outriggers Up Lift Capacity Full Height: 6000 lb / 2721.55 kg
- Outside Turning Radius: 14 ft 2 in. / 4.32 m
- Capacity - Fuel Tank: 35 gal. / 132.49 L
- Service Brake Type: Wet Multi-Disc
- Speed - Maximum Telescope In: 15.1 sec.
- Speed - Maximum Travel: 20 mph / 32.19 km/h
- Speed - Maximum Telescope Out: 17.2 sec.
- Machine Width: 8 ft 6 in. / 2.59 m
- Machine Height: 8 ft 4 in. / 2.54 m
- Speed - Maximum Lower: 15 sec.
- Outriggers Up Lift Capacity Full Reach: 2000 lb / 907.18 kg
- Outriggers Up Max Forward Reach: 26 ft 7 in. / 8.1 m
- Operating Vehicle Weight: 27300 lb / 12383.07 kg
- Engine Manufacturer: Cummins
- Wheelbase: 10 ft / 3.04 m
Features
- New, intuitive single joystick controls all boom functions
- Take a virtual tour of the SkyTrak telehandlers
- Increased operator confidence with Stabil-Trak rear axle stabilization system when placing a load
- Redesigned cab includes new dashboard, integrated arm rest and optional air conditioning
- Maximize productivity with improved boom speeds
- Optional 74 hp engine doesn’t require Diesel Exhaust Fluid (DEF) and meets Tier 4 Final regulations
- Greater job site versatility—rear counterweight includes an integrated tow hitch
