Key Specs
- Platform Height: 80 ft / 24.38 m
- Platform Capacity – Restricted: 1000 lb / 453.59 kg
- Platform Capacity – Unrestricted: 500 lb / 226.80 kg
- Horizontal Outreach: 53 ft / 16.15 m
Key Features
- Get the extra reach and versatility you need with the best reach envelope in the industry
- With Workstation in the Sky® accessories, you will have all you need to get the job done
- Advanced Design Electronics System reduces your costs by increasing your fuel efficiency and reducing emissions
Specifications
- Axle Oscillation: 0 in. / 0 m
- Machine Height: 9 ft 10 in. / 3 m
- Ground Clearance: 11 in. / 0.28 m
- Platform Capacity - Restricted: 1000 lb / 453.59 kg
- Swing Type: Continuous
- Platform Dimension B: 8 ft / 2.44 m
- Engine Type - Dual Fuel: Ford MSG425 84hp
- Machine Width: 8 ft 2 in. / 2.49 m
- Engine Type - Diesel: DEUTZ TD 2.9L Tier 4 Final 67 hp
- Platform Dimension A: 3 ft / 0.91 m
- Drive Speed - 4WD: 3 mph / 4.83 km/h
- Up and Over Height: 32 ft 1 in. / 9.78 m
- Tailswing: 2 ft 6 in. / 0.76 m
- Platform Height: 80 ft / 24.38 m
- Auxiliary Power: 12 Volts DC
- Swing: 360 Degrees
- Capacity - Hydraulic Reservoir: 40 gal. / 151.42 L
- Gradeability - 4WD: 45 %
- Tire Size: 15-625 Pneumatic
- Horizontal Outreach: 53 ft / 16.15 m
- Maximum Ground Bearing Pressure: 76 psi / 5.32 Kg/cm2
- Platform Capacity - Unrestricted: 500 lb / 226.80 kg
- Machine Length: 36 ft 11 in. / 11.25 m
- Turning Radius - Outside (2WS): 19 ft 8 in. / 5.99 m
- Horizontal Jib Rotation: 0 Degrees
- Machine Weight: 34130 lb / 15481.11 kg
- Turning Radius - Outside (4WS): 11 ft 7 in. / 3.53 m
- Gradeability - 2WD: 30 %
- Capacity - Fuel Tank: 39 gal. / 147.63 L
Features
- Advanced Design Electronics System reduces your costs by increasing your fuel efficiency and reducing emissions
- Get the extra reach and versatility you need with the best reach envelope in the industry
- With Workstation in the Sky® accessories, you will have all you need to get the job done
