Key Specs
- Platform Height: 15 ft 4 in. / 4.67 m
- Machine Width: 2 ft 6 in. / 0.75 m
Key Features
- Five platform options with exclusive “Quick Change” mountings for one-minute change-outs
- Exclusive Point & Go® single joystick control operates drive and steer, and lift and lower
- Rigid mast for operator comfort and stability
Specifications
- Ground Clearance: 2 in. / 0.05 m
- Platform Capacity: 500 lb / 226.80 kg
- Maximum Drive Height: 15 ft 4 in. / 4.67 m
- Platform Dimension A: 2 ft 2 in. / 0.66 m
- Drive Speed - Platform Lowered: 3.5 mph / 5.63 km/h
- Machine Length: 4 ft 6 in. / 1.36 m
- Machine Height: 6 ft 6 in. / 1.98 m
- Machine Width: 2 ft 6 in. / 0.75 m
- Drive Speed - Platform Elevated: 0.6 mph / 0.97 km/h
- Wheel Size - Front Caster: 8 x 2.5"
- Platform Dimension B: 2 ft 4 in. / 0.71 m
- Batteries: Two Sealed 100 AH 12 Volt
- Working Height: 21 ft 4 in. / 6.5 m
- Maximum Lift Height: 15.3 ft / 4.66 m
- Gradeability: 20 %
- Ground Entry Height: 1 ft 7 in. / 0.48 m
- Machine Weight: 2325 lb / 1054.60 kg
- Drive System: 4 Brush Direct Electric
- Wheel Size - Rear: 12.62 x 4"
Features
- Exclusive Point & Go® single joystick control operates drive and steer, and lift and lower
- Five platform options with exclusive “Quick Change” mountings for one-minute change-outs
- Rigid mast for operator comfort and stability
