Key Specs
- Platform Height: 45 ft / 13.72 m
- Platform Capacity – Unrestricted: 550 lb / 249.48 kg
- Horizontal Outreach: 25 ft / 7.62 m
Key Features
- Improved multifunction capability increases productivity
- More durability and serviceability thanks to the new DuraTough hood design
- Larger capacity at 550 lb
Specifications
- Capacity - Fuel Tank: 16 gal. / 60.57 L
- Maximum Ground Bearing Pressure: 48 psi / 3.36 Kg/cm2
- Turning Radius - Outside: 15 ft 8 in. / 4.78 m
- Platform Capacity - Unrestricted: 550 lb / 249.48 kg
- Platform Dimension A: 2 ft 6 in. / 0.76 m
- Jib - Range of articulation: 144 Degrees
- Machine Width: 7 ft 9 in. / 2.35 m
- Tailswing: 0 in. / 0 m
- Up and Over Height: 24 ft / 7.32 m
- Drive Speed - 4WD: 4.3 mph / 6.84 km/h
- Platform Height: 45 ft / 13.72 m
- Platform Dimension B: 6 ft / 1.83 m
- Horizontal Outreach: 25 ft / 7.62 m
- Machine Weight: 12650 lb / 5737.94 kg
- Swing Type: Non-Continuous
- Auxiliary Power: 12 Volts DC
- Tire Size: 33/1550 x 16.5 Superwide
- Machine Length: 21 ft 7 in. / 6.58 m
- Ground Clearance: 1 ft / 0.3 m
- Machine Height: 7 ft 5 in. / 2.27 m
- Engine Type - Diesel: Deutz D2.9 L4 Tier 4 Final 49 hp
- Capacity - Hydraulic Reservoir: 36 gal. / 136.27 L
- Axle Oscillation: 4 in. / 0.1 m
- Engine Type - Dual Fuel: GM Vortec 3000 MPFI 82 hp
- Gradeability - 4WD: 45 %
- Swing: 355 Degrees
Features
- More durability and serviceability thanks to the new DuraTough hood design
- Larger capacity at 550 lb
- Improved multifunction capability increases productivity
