H30-35FT H40FTS
Rugged and Durable in Your Most Challenging Applications
This lift truck series is designed for indoor and outdoor use and ideally suited for a wide variety of applications such as general warehousing, wood pallet / skid manufactures, and short term rentals.
The H30-40FTS series lift trucks were designed with the same unparalleled commitment to quality and dependability as all Hyster Fortis lift trucks. We combined the toughest engine components with customized performance to create a rugged, durable lift truck that thrives in your challenging applications.
Model Table
| Model | Load Capacity (lbs) | Engine | Transmission | Maximum Travel Speed (mph) | Maximum Lift Speed (ft/min) |
|---|---|---|---|---|---|
| H30FT | 3000 | PSI 2.0L | Electronically Controlled Powershift 1 Speed, DuraMatch Electronic 1 Speed | 13.4 | 118 |
| H35FT | 3500 | PSI 2.0L | Electronically Controlled Powershift 1 Speed, DuraMatch Electronic 1 Speed | 13.4 | 118 |
| H40FTS | 4000 | PSI 2.0L | Electronically Controlled Powershift 1 Speed, DuraMatch Electronic 1 Speed | 13.4 | 118 |
- Capacity: 3,000 - 4,000 lbs
- Max Height: 222
- Max Weight: 4000 lbs
- Series Title: H30-35FT H40FTS
- Type: 4 WHEEL PNEUMATIC TIRE
- Weight: lbs
- Proven tough, Pacesetter VSM industrial onboard computer manages truck operation to maintain world-class dependability and maximize uptime.
- Superior ergonomic features including E-hydraulic controls, an infinitely adjustable steer column, and 4 choices of seats keep our operators more comfortable and help them work more productively.
- Controlled power reversal feature virtually eliminates tire spin, increasing tire life by up to 50%. This feature is programmable to match needs from delicate to aggressive settings for optimal productivity.
- Leak-free O-ring face seals help maximize uptime and an in-tank filter increases hydraulic fluid filtration by 60% for particles down to 10 microns significantly extending component life and creating a cleaner overall operation.
Product Brochure
H30-35FT, H40FTS
Technical Guide
H30-35FT, H40FTS
