41AM - Briggs Equipment

Key Specs

  • Platform Height: 40 ft 9 in. / 12.42 m
  • Machine Width: 2 ft 5 in. / 0.74 m

Key Features

  • Most rigid mast in the industry for operator comfort and stability
  • Six-wheel design for improved maneuverability
  • Long battery duty cycles and an automatic charger for more productivity

JLG 41AM

Key Specs

  • Platform Height: 40 ft 9 in. / 12.42 m
  • Machine Width: 2 ft 5 in. / 0.74 m

Key Features

  • Most rigid mast in the industry for operator comfort and stability
  • Six-wheel design for improved maneuverability
  • Long battery duty cycles and an automatic charger for more productivity

Need pricing or more information on this unit?

Whether it is the new or used piece of equipment that has caught your eye we want to help you find the purchasing option that best meets your needs and budget.

Specifications

  • Working Height: 47 ft / 14.33 m
  • Ground Entry Height: 1 ft 7 in. / 0.48 m
  • Machine Weight-AC: 1100 lb / 498.95 kg
  • Outriggers Up Max Lift Height: 40.8 ft / 12.44 m
  • Platform Dimension B: 2 ft 2 in. / 0.65 m
  • Platform Height: 40 ft 9 in. / 12.42 m
  • Wheel Size - Rear: 10 x 2"
  • Platform Dimension A: 2 ft 2 in. / 0.66 m
  • Machine Width: 2 ft 5 in. / 0.74 m
  • Wheel Size - Front Caster: 6 x 2"
  • Machine Length: 4 ft 10 in. / 1.46 m
  • Outrigger Footprint Width: 6 ft 7 in. / 2.01 m
  • Platform Capacity: 300 lb / 136.08 kg
  • Machine Weight-DC: 1230 lb / 557.92 kg
  • Machine Height: 8 ft 8 in. / 2.64 m
  • Outriggers or Stabilizers: Yes

Features

  • Most rigid mast in the industry for operator comfort and stability
  • Six-wheel design for improved maneuverability
  • Long battery duty cycles and an automatic charger for more productivity
