Make JLG
Model 660SJC
Type Telescopic Booms

Key Specs

  • Platform Height: 65 ft 7 in. / 19.99 m
  • Platform Capacity - Restricted: 750 lb / 340.19 kg
  • Platform Capacity - Unrestricted: 550 lb / 249.48 kg
  • Horizontal Outreach: 57 ft 1 in. / 17.39 m

Key Features

  • For your toughest jobs and terrains, the 600 Crawler Series provides the mobility you need
  • Single drive / steer joystick for one-handed operation
  • Zero turning radius to get around the jobsite easier
  • Auxiliary Power: 12 Volts DC
  • Capacity - Fuel Tank: 31 gal. / 117.35 L
  • Capacity - Hydraulic Reservoir: 34 gal. / 128.70 L
  • Drive Speed - 4WD: 1.6 mph / 2.57 km/h
  • Engine Type - Diesel: Deutz TD2.9L4 Tier4 Final
  • Gradeability - 4WD: 55 %
  • Ground Clearance: 1 ft 3 in. / 0.38 m
  • Horizontal Outreach: 57 ft 1 in. / 17.39 m
  • Jib - Range of articulation: 132 Degrees
  • Machine Height: 8 ft 2 in. / 2.5 m
  • Machine Length: 35 ft 5 in. / 10.79 m
  • Machine Weight: 29339 lb / 13307.95 kg
  • Machine Width: 8 ft 2 in. / 2.49 m
  • Maximum Ground Bearing Pressure: 6.5 psi / 0.46 Kg/cm2
  • Platform Capacity - Restricted: 750 lb / 340.19 kg
  • Platform Capacity - Unrestricted: 550 lb / 249.48 kg
  • Platform Dimension A: 3 ft / 0.91 m
  • Platform Dimension B: 8 ft / 2.44 m
  • Platform Height: 65 ft 7 in. / 19.99 m
  • Swing: 360 Degrees
  • Swing Type: Continuous
  • Tailswing: 4 ft / 1.22 m
  • Track Width: 20in.
  • Zero turning radius to get around the jobsite easier
  • For your toughest jobs and terrains, the 600 Crawler Series provides the mobility you need
  • Single drive / steer joystick for one-handed operation
