Platform Capacity - Restricted: 1000 lb / 453.59 kg
Platform Capacity - Unrestricted: 600 lb / 272.16 kg
Horizontal Outreach: 33 ft / 10.06 m
Key Features
Industry-leading Capacity - Dual capacity and 600-lb unrestricted/1,000-lb restricted capacity allow operators to carry more tools
Improved Fuel Efficiency - Variable-speed engine control reduces operating costs and engine wear and tear
Increased Work Envelope - 360 degrees of continuous rotation lets operators reach more and reposition less
Superior Terrainability - Full-size tracks make areas with soft ground, mud, sand and snow accessible
Enhanced Productivity - Faster function speeds and multifunction capability allow operators to perform more functions at once
More Durability - DuraTough hood is highly impact resistant for less maintenance and greater protection of interior components
SkyGuard® Enhanced Control Panel Protection – Standard feature that helps decrease the likelihood of operator caught-between injuries while working at height
Auxiliary Power:
12 Volts DC
Capacity - Fuel Tank:
22 gal. / 83.28 L
Capacity - Hydraulic Reservoir:
36 gal. / 136.27 L
Drive Speed - 4WD:
1.6 mph / 2.57 km/h
Engine Type - Diesel:
Deutz D2.9L4 Tier 4 Final 49 hp (36.4 kW)
Gradeability - 4WD:
51 %
Ground Clearance:
1 ft 1 in. / 0.32 m
Horizontal Outreach:
33 ft / 10.06 m
Machine Height:
7 ft 8 in. / 2.32 m
Machine Length:
24 ft 10 in. / 7.57 m
Machine Weight:
14559 lb / 6603.85 kg
Machine Width:
7 ft 4 in. / 2.24 m
Maximum Ground Bearing Pressure:
5.2 psi / 0.36 Kg/cm2
Platform Capacity - Restricted:
1000 lb / 453.59 kg
Platform Capacity - Unrestricted:
600 lb / 272.16 kg
Platform Height:
39 ft 7 in. / 12.05 m
Swing:
360 Degrees
Tailswing:
3 ft 2 in. / 0.97 m
Track Width:
1 ft 4 in. / 0.4 m
More Durability - DuraTough hood is highly impact resistant for less maintenance and greater protection of interior components
Increased Work Envelope - 360 degrees of continuous rotation lets operators reach more and reposition less
Improved Fuel Efficiency - Variable-speed engine control reduces operating costs and engine wear and tear
SkyGuard® Enhanced Control Panel Protection – Standard feature that helps decrease the likelihood of operator caught-between injuries while working at height
Enhanced Productivity - Faster function speeds and multifunction capability allow operators to perform more functions at once
Superior Terrainability - Full-size tracks make areas with soft ground, mud, sand and snow accessible
Industry-leading Capacity - Dual capacity and 600-lb unrestricted/1,000-lb restricted capacity allow operators to carry more tools
