Make JLG
Model 600A
Type Engine Powered Boom Lifts

Key Specs

  • Platform Height: 60 ft 5 in. / 18.42 m
  • Platform Capacity - Restricted: 1000 lb / 453.59 kg
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Horizontal Outreach: 39 ft 7 in. / 12.07 m

Key Features

  • Best reach envelope in its class
  • Optional articulating jib gets you into hard-to-reach places
  • Unmatched maneuverability for confined work areas
  • Equipped with a fuel-efficient Tier 4 engine
  • Auxiliary Power: 12 Volts DC
  • Axle Oscillation: 8 in. / 0.2 m
  • Capacity - Fuel Tank: 30 gal. / 113.56 L
  • Capacity - Hydraulic Reservoir: 30.6 gal. / 115.83 L
  • Drive Speed - 2WD: 4.3 mph / 6.84 km/h
  • Engine Type - Diesel: DEUTZ TD 2.9L Tier 4 Final 67 hp
  • Engine Type - Dual Fuel: Ford MSG425 84hp
  • Gradeability - 2WD: 30 %
  • Gradeability - 4WD: 45 %
  • Ground Clearance: 1 ft / 0.29 m
  • Horizontal Outreach: 39 ft 7 in. / 12.07 m
  • Jib - Range of articulation: 0 Degrees
  • Machine Height: 8 ft 4 in. / 2.54 m
  • Machine Length: 26 ft 5 in. / 8.05 m
  • Machine Weight: 21640 lb / 9815.74 kg
  • Machine Width: 8 ft 2 in. / 2.49 m
  • Maximum Ground Bearing Pressure: 77 psi / 5.39 Kg/cm2
  • Platform Capacity - Restricted: 1000 lb / 453.59 kg
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Platform Dimension A: 3 ft / 0.91 m
  • Platform Dimension B: 8 ft / 2.44 m
  • Platform Height: 60 ft 5 in. / 18.42 m
  • Swing: 360 Degrees
  • Swing Type: Continuous
  • Tailswing: 0 in. / 0 m
  • Tire Size: IN355/55D-6.25 Low Profile
  • Turning Radius - Outside (2WS): 17 ft 7 in. / 5.36 m
  • Turning Radius - Outside (4WS): 9 ft 6 in. / 2.9 m
  • Up and Over Height: 26 ft 7 in. / 8.1 m
  • Equipped with a fuel-efficient Tier 4 engine
  • Best reach envelope in its class
  • Optional articulating jib gets you into hard-to-reach places
  • Unmatched maneuverability for confined work areas
